Features:
Easy operation with electrical control box, In-ground or on-ground mounted, With rear sliding plate for doing wheel alignment. Front turn table place with position adjustable for different kinds of vehicles. Double oil cylinder structure allows much easier leveling operation, 24V power control box guards against unexpected hurt or injury. Limit switch installation protect the cylinder and power unit for long time use.
Specification:
|
Model |
Lifting Capacity |
Lifting
Height |
Host Rise/ Drop time |
Client
Capacity |
Client Lift
Height |
Client Rise/
Drop time |
Power of Motor |
Power
Supply |
|
XRDSA3.5/4.0 |
3.5ton,4.0ton |
1850mm |
45/38 |
3500Kg |
450mm |
15/14s |
2.2kw |
380V/220V |
|
|
